All New Series Top view LED Neon Flex 24V 10x10mm 8W IP66 5M/Roll Mini Size With 3M Tape

    Buy cheap All New Series Top view LED Neon Flex 24V 10x10mm 8W IP66 5M/Roll Mini Size With 3M Tape from wholesalers

    Buy cheap All New Series Top view LED Neon Flex 24V 10x10mm 8W IP66 5M/Roll Mini Size With 3M Tape from wholesalers
    • Buy cheap All New Series Top view LED Neon Flex 24V 10x10mm 8W IP66 5M/Roll Mini Size With 3M Tape from wholesalers

    All New Series Top view LED Neon Flex 24V 10x10mm 8W IP66 5M/Roll Mini Size With 3M Tape

    Ask Lasest Price
    Brand Name : LEDCORP
    Model Number : LC180-E2835-1010W/WW-24
    Certification : ISO9001,CE,UL,TUV, RoHS
    Price : Welcome to your inquiry
    Payment Terms : T/T , PayPal
    Supply Ability : 500,000mters per month
    Delivery Time : 15 working days
    • Product Details
    • Company Profile

    All New Series Top view LED Neon Flex 24V 10x10mm 8W IP66 5M/Roll Mini Size With 3M Tape

    DC 24V LED NEON FLEX CREE EPISTAR CHIP IP66 IP67 IP68 CE UL TUV 5 YEARS


    Product advantages:

    • Color Consistency, only one bin
    • High Efficacy, 90-165lm/w
    • High CRI, 80+,90+,95+
    • Color purity: we use quality chip, phosphor golden wires and copper holder, make the SDCM<4
    • Long Lifespan: >35000 Hrs
    • No dark and uninterrupted Led strip
    • High brightness, low decay, low power consumption, LM-80 Tested
    • Be able to give soul space, and increase the dynamics of the space, making the space brighter.

    Features:

    • High Efficacy 2216SMD as light source
    • LM-80 TESTED
    • Epistar/Cree/Bridgelux/Samsung/Osram/SanAn Chip
    • ONLY ONE BIN
    • COLOR CONSISTENCY
    • RA80+,90+
    • 3 Years Warranty
    • 3M adhersive tape
    • OEM / ODM are welcomed.
    • Available in IP20,IP44,IP54,IP62,IP65,IP66,IP67,IP68 rating and nano series

    Application area:

    • Surrounding Lighting
    • Auxiliary Lighting
    • Theme Lighting
    • Decorative lighting
    • Linear lighting

    Technical details:


    Details

    Item

    Unit

    Specification

    Physical data

    LED type

    SMD

    2835SMD

    LED Qty /meter

    LED/m

    180

    Dimensions

    mm

    10*10*5000 (W*H*L)

    Type of protection

    IP

    IP66 / IP67 / IP68

    Working temperature

    °C

    -30°C - 60°C

    Electrical data

    Power

    W/M

    8

    Voltage

    VDC

    24V

    Optical data

    Luminous flux

    LM/M

    240

    Beam angle

    Degrees

    120

    Light color



    Warm white / Natural white / White

    Color BINs



    1 BIN

    Color temperature

    K

    Warm white : 2400 / 2700-3000

    Natural white : 4000-4500

    White : 5000-5500 / 6000-6500

    Color rendering index

    CRI

    80+,90+

    Order reference

    HS code

    94054090


    Dimension:





    Packing details:


    Items

    Packaging unit

    meters per box

    reels per box

    Dimensions(mm) LxWxH

    Gross weight(kg)

    Volume(cbm)

    IP66 / IP68 Neon

    Shipping carton box

    150m

    30reel

    500*400*250

    15

    0.05
